RH - 6032A single wire and vertical burning test machine (high-grade type/zone temperature type/ventilation cabinet)
Product features
1, This machine is UL lab, customization model is suitable for the determination of single insulated wire and cable, control, crosslinking, elevator, Marine, mining cable not spreading combustion performance. Still can do self-extinguishing high low smoke zero halogen flame retardant polyolefin insulation material and 105 ℃ low smoke zero halogen flame retardant olefin irradiation vertical burning test of insulation material.
2, This device is for single wire and cable resistance to combustion test equipment, the equipment has high accuracy, automatic timing, the end of the automatic test, easy operation, etc.
3, The device by the control box, burning lamp burning box, propane, solenoid valve, igniter, gas pipe, pressure regulating valves, gas meter (1) propane 2, air and signal control system.
4, 2 sets of gas input configuration/flow/pressure/control system and Shared cover 1 (independent control, meet two different series of standardized and easy to operate, save time).
5, Body increase anti-corrosion design and processing, improve and extend the anticorrosion ability, time.
Standards in accordance with
GB / / IEC60332 T18380.11-2008-1-1:4;
GB / / IEC60332 T18380.12-2008-1-04 I completely;
GB/T 18380.13 2008 / IEC60332-1-04 his;
GB / / IEC60332 T18380.21-2008-2-1:4;
GB/T18380.22-2008 / IEC 60332-2-04 I completely;
GB / / IEC60695 T5169.14-2007-11 - \"03
The main parameters
1, burner/Bunsen buner: GB / / IEC60332 T18380.11-2008-1-1:4, GB / / IEC60332 T18380.12-2008-1 - \"04, GB/T
/ IEC60332-1-18380.13-2008 3:20 04 adopts the nominal power is 1 kw burner, in line with the GB/T5169.14-2007 standard; GB / / IEC60332 T18380.21-2008-2-1:4, GB/T18380.22-2008 / IEC 60332-2 - \"04 USES the propane burner type (diffusion flame).
2, test position: blue flame is 475 mm from edge of stent on the contact point, the burner axis perpendicular to the sample of 45 ° Angle;
3, The flame height: blue flame 55 + / - 5 mm, outer flame 180 mm + / - 10 mm, other height is adjustable.
4.Using installation: 600 + 25 mm in length, clamping diameter: 1 ~ 30 mm or sectional area was 0.5 or more single wire and cable;
5, Sample holder: stents with the distance of 550 mm;
6, The burning time: 0-999.9 s + 0.1 s adjustable, ignition choose manual or automatic way;
7, The burning time: 0-999.9 s + 0.1 s adjustable, set time continuous samples on combustion flame;
8, Combustion gas, high purity 95% technical grade propane gas (own);
9, Gas flow range: flowmeter, 100 ~ 1000 ml/min (standard 650 ml/min + 30 ml/min).
10, The air flow range: 1 ~ 10 + / - 0.5 L/min (standard 10 L/min + / - 0.5 L/min).
11, The air pressure gauge: 0 ~ 0.75 kpa range adjustment (0.1 kpa) standard
12, Temperature testing scope: digital display thermometer, 0 ~ 1000 ℃;
13, Flame temperature requirement: from 100 + 2 ℃ up to 700 + 3 ℃ available within 45 + / - 5 s;
14, Temperature measuring thermocouple: 0.5 mm Φ armoured K type thermocouple (NiCr/leicester);
15, Temperature measuring copper: Φ 9 mm imported high purity electrolytic copper pieces, embedded thermocouple before drilling weight W10 + / - 0.05 g;
16, Box: SUB316 imports of stainless steel, on three sides by the close, open and positive in the black paint spraying, illuminance 20 lx or less;
17, Cover size: 300 mm to 25 mm wide x 450 mm + 25 deep x 1250 + 25 mm high (standard) * 2 sets, convenient for two series of standard test;
18, Inside the box size: about 1.2 cubic meters
19, Carton size: 700 mm x 450 mm wide deep x 1500 mm high;
20, Fume hood, bring their own;
21, Power AC220V, 50 hz, 6 a.
22, Environmental protection treatment system
|
