Mentioned

RH - 6033 UL combustion chamber (UL lab custom type) Hong Kong UL lab, customization model reference UL, UL Taiwan and Hong Kong UL lab many years of experience in the United States, the strengths and weaknesses, attract and improvement of the world's best-known manufacturers similar testing machine from our company independent research and development of the current domestic most advanced conforms to UL 1581, UL 2556, UL 94, ASTM D 5025 and ASTM D 5207 standard UL combustion chamber, and through the UL harsh assessment and acceptance. The models all Settings and burning projects through PLC control and color touch screen display, intuitive, simple, easy to use. Such as the temperature calibration system, VW - 1, FT2 combustion test project, etc. Combustion test done by the system control, avoid manually at random and error. Beautiful atmosphere, high precision, convenience operation and high sealing really reached the international level and UL approved laboratories.

Meet the standard

UL 1581, UL 2556, UL510,UL1441

UL 94

ASTM D 5025

ASTM D 5207

CAS C22.2 No. 173 (CSA C22.2 No. 0.17)

UL746C 3/4 Inch Flame test

5 Inch UL746C Flame test,

IEC60695-11-5 Needle Flame Test

IEC60695-11-4, UL 60695 Annex a. 2 20 mm (50 w)

......

Product features

Outstanding design.

1. Design the world's most famous producer: American Govmark, British FTT, the United States Ametek (former U.S. Atalas), ITW (the former Italy CEAST) in the United States, to learn their own advantages and improve insufficient, also increased many innovation alone, such as burner operation mode: dynamic and change the burner ignition Angle 45 ° and 90 °.

2. Research and development and design to get UL Hong Kong, UL Taiwan, senior engineer advice and UL American lab, refer to their years test experience and advice.

High sealing:

Specially design and the use of special high sealing material, can pass in the smoke test, recognized by many laboratory (UL Hong Kong lab/UL Taiwan lab/UL laboratory, USA), the first domestic manufacturer without the level requirements.

High precision: (optional)

Each manufacturer are currently using flow meter, if customers need more accurate test results, we are equipped with the world's top brand and UL experiment to recommending room Alicat display mass flowmeter. Parameter adjustment, readability, convenience and strong stability, the accuracy of 2% or less (standard requirement for plus or minus 2%) is much higher than other same type products, currently has several laboratories and manufacturers use.

Operational convenience:

1. All the test procedure is controlled by PLC, test parameters and test mode through the menu Settings through the color LCD touch screen display.

2. The mechanical structure design and operation mode considering the human body engineering not only, more focused on testing the convenience of operation, operability. Such as automatic ignition burner, school temperature automatic judgement function; Test temperature and test time displayed on the touch screen, easy to observe and record.

3. Simply start a button the system will automatically test, and don't need to manually make the human error operating reduce to a minimum, really ensure the test of time

And the reliability of the results.

4. Humanized automatic electrical and mechanical structure design maximum extent, reduce the labor intensity of the operator, more suitable for.

5. Add ruler, plus the large clamp (clamping OD15mm and the following wire), etc.

Import parts list (made in USA) :

1. The burner manufacturers: HUMBOLDT MFG. CO.

2. The mass flowmeter producers: Alicat Scientific, Inc.

3. Import thermocouple and connector manufacturer, Omega Engineering.

4. U type differential pressure meter manufacturers: Dwyer Instruments Pty Ltd.
